Properties of rubber bumpers
Rubber bumpers are elements made of high-quality rubber, which are used to protect walls, poles, devices and other elements from impacts of vehicles or other objects when approaching.
Thanks to their strength and flexibility, bumpers absorb impact energy, minimizing the risk of damage.
Advantages of rubber bumpers:
- protecting vehicles and buildings from damage
- optimization of docking processes
- facilitating the correct positioning of the vehicle
- long service life
- easy installation
- aesthetic appearance
Construction of rubber bumpers
Rubber bumpers are made of high-quality flexible EPDM with a thickness of 100 mm. Rubber bumpers are characterized by high durability and service life.
Rear dimension (mm) 500x250x100, spacing between mounting screws is approx. 250 mm. The weight of the set is about 28 kg.
Additional options for rubber bumpers:
- It is possible to order a protective plate, made of galvanized steel with a thickness of 10 mm, which protects the front part of the rubber bumper against abrasion. Slab dimensions: 500x250x10 mm.
Download files:
Loading systems
Download after providing data:
CAD drawings (rfa, dwg) and PDF files
